The Induskey INK106 Portable Pump-Suction Multi-Parameter Gas Analyzer is an industrial-grade multi-gas monitoring instrument designed for real-time environmental and process gas detection applications. The system supports flexible monitoring of 1–10 target gases simultaneously and can additionally integrate PM2.5, PM10, temperature, and humidity monitoring functions.
Equipped with an integrated vacuum sampling pump, intelligent sensor platform, high-definition touchscreen interface, and large-capacity data storage capability, the INK106 is suitable for industrial safety monitoring, environmental inspection, emergency response, petrochemical applications, wastewater treatment, confined space monitoring, and air quality analysis.
The system supports multiple sensor technologies including electrochemical, infrared, PID, catalytic combustion, MOS, semiconductor, and optical sensing technologies.
|
Parameter |
Specification |
|
Product Model |
INK106 |
|
Product Type |
Portable Pump-Suction Multi-Parameter Gas Analyzer |
|
Application Type |
Portable / Fixed Dual-Use |
|
Sampling Method |
Pump-Suction Type |
|
Power Supply |
220V DC power supply with integrated rechargeable lithium battery |
|
Battery Operating Time |
More than 10 hours |
|
Gas Detection Capacity |
1–10 gases simultaneously |
|
Supported Gas Types |
Combustible gases, toxic gases, VOC gases |
|
PM2.5 Range |
0–1000 ug/m3 |
|
PM10 Range |
0–1000 ug/m3 |
|
Temperature Range |
-40°C to +80°C |
|
Humidity Range |
0–100%RH |
|
Detection Range |
0–1 / 2 / 5 / 10 / 50 / 100 / 500 / 1000 / 5000 / 10000 / 50000 (depending on sensor and sensing technology) |
|
Resolution |
0.001 / 0.01 / 0.1 / 1 / 2 / 5 (depending on sensor and sensing technology) |
|
Detection Units |
PPM, PPB, %LEL, %VOL, mg/m3, ug/m3, g/m3, g/l, mol/mol, umol/mol |
|
Sensor Technologies |
Electrochemical, Infrared, Catalytic Combustion, PID, Semiconductor, MOS, Optical Waveguide |
|
Communication Methods |
RS485 / RS232 / USB / WIFI / Bluetooth / GPRS |
|
Data Interface |
USB ×2 / RS232 ×1 |
|
Display |
7-inch HD Touchscreen |
|
Display Modes |
List View / Grid View |
|
Accuracy |
≤±3% (depending on monitored parameter) |
|
Repeatability |
≤±1% (depending on monitored parameter) |
|
Linear Error |
≤±1% (depending on monitored parameter) |
|
Operating Temperature |
-20°C to +50°C |
|
Operating Humidity |
10–95%RH |
|
Operating Pressure |
86–106 Kpa |
|
Power Consumption |
≤18W |
|
Vacuum Pump Flow Rate |
1.1L/min |
|
Data Storage Capacity |
More than 100,000 records |
|
Calibration Function |
Supported |
|
Intelligent Reminder Function |
Supported |
|
Dimensions |
275 × 220 × 330 mm |
|
Weight |
Approx. 6 kg |
The INK106 supports multiple industrial sensing technologies:
The platform supports flexible sensor configuration depending on application requirements.
The INK106 supports both wired and wireless communication methods for industrial monitoring integration.
|
Optional Accessory |
Description |
|
High-Temperature Probe |
Supports direct sampling in environments up to 800°C |
|
High-Efficiency Dust & Moisture Filter |
Suitable for high-humidity and dusty environments |
|
Extendable Sampling Rod |
Suitable for confined spaces and difficult-access areas |
The INK106 is suitable for:
275 × 220 × 330 mm
Approx. 6 kg
