Name: Induskey INK434 Vehicle-Mounted Environmental Monitor
Brand: IndusKey.com
SKU: INK434
Rating: 5 (1 reviews)

Description

1. Product Overview

The INK434 Vehicle-Mounted Environmental Monitor is a compact, all-in-one automatic weather station purpose-built for mobile emergency and traffic meteorological monitoring. It delivers real-time, multi-parameter environmental data including wind direction/speed, temperature, humidity, precipitation, pressure, solar radiation, and solar temperature. Designed for robust deployment in mobile scenarios, it features IP65 protection, concealed wiring, and strong magnetic mounting, making it ideal for emergency response vehicles, mobile meteorological units, and traffic patrol fleets to provide on-site decision-support data for meteorological and traffic safety operations.

2. Sensing Technology & Self-Cleaning System

Sensing Technology:
- Ultrasonic Wind Sensors: Non-contact ultrasonic transducers measure wind speed (0-70 m/s) and direction (0-359°) with high precision, eliminating moving parts for durability.
- Integrated Environmental Sensors: Digital probes for temperature (-40~+80°C), humidity (0-100% RH), atmospheric pressure (300-1100 hPa), and optical rainfall (0-999.9 mm) provide accurate, real-time readings.
- Radiation Sensors: A pyranometer measures total solar radiation (0-2000 W/m²) for solar energy and environmental monitoring applications.
Environmental Adaptation:
- Probe Heating System: Built-in heating elements prevent frost, ice, and condensation buildup on sensors in harsh cold environments, ensuring continuous operation down to -40°C.
- IP65 Enclosure: Sealed housing protects against dust, rain, and splashing water, suitable for all weather conditions.

3. Key Features & Competitive Advantages

Feature	Competitive Advantage
Integrated, Concealed Wiring Design	Clean installation, reduced cable damage risk, improved reliability for mobile use
Fully Customizable Monitoring Parameters	Tailor sensor suites to specific use cases (emergency response, traffic safety, research)
IP65 Protection Rating	Rugged performance in rain, snow, dust, and high-humidity environments
Probe Heating for Harsh Conditions	Maintains accuracy in temperatures as low as -40°C, preventing sensor freeze-up
Strong Magnetic Bracket	Quick, secure mounting on vehicle roofs without permanent modifications
Electronic Compass Calibration	True mobile monitoring with accurate wind direction readings regardless of vehicle orientation
Built-in GPS & Time Synchronization	Automatic geotagging and time-stamping of data for location-aware applications
Multi-Protocol Output (RS485/RS232/GPRS)	Seamless integration with industrial control systems, SCADA, and cloud platforms

4. Technical Specifications

Parameter	Specification
Output Interfaces	RS485 / RS232 / GPRS wireless
Power Supply	DC 12 V / AC 220 V; Power consumption: 40 mA
Operating Temperature	-40 ~ +70 °C
Communication Protocol	Standard Modbus; customizable
Temperature	Range: -40 ~ +80 °C; Resolution: 0.1 °C; Accuracy: ±0.2 °C
Humidity	Range: 0 ~ 100 % RH; Resolution: 0.1 % RH; Accuracy: ±2 % (≤80 %), ±5 % (>80 %)
Atmospheric Pressure	Range: 300 ~ 1100 hPa; Resolution: 0.1 hPa; Accuracy: ±0.3 hPa
Optical Rainfall	Range: 0 ~ 999.9 mm; Resolution: 0.1/0.2 mm; Accuracy: ±10 %
Ultrasonic Wind Direction	Range: 0 ~ 359°; Resolution: 1°; Accuracy: ±3°
Ultrasonic Wind Speed	Range: 0 ~ 70 m/s; Resolution: 0.1 m/s; Accuracy: ±(0.3+0.03V) m/s
Total Radiation	Range: 0 ~ 2000 W/m²; Resolution: 1 W/m²; Accuracy: <5 %

5. Applications

Mobile Emergency Meteorological Response: Deployed on emergency response vehicles to collect real-time weather data at disaster sites.
Traffic Patrol & Highway Safety: Mounted on traffic police vehicles to monitor road weather conditions (wind, rain, visibility) for safety alerts.
Meteorological Research & Field Surveys: Used in mobile research stations for environmental and climate studies in remote areas.
Railway & Transit Operations: Installed on maintenance vehicles to monitor trackside weather conditions and support safety decisions.
Maritime & Coastal Patrol: Mounted on patrol boats to monitor wind, temperature, and humidity in coastal and offshore environments.
Smart City & Urban Monitoring: Deployed on municipal vehicles for real-time urban environmental data collection.
Construction & Infrastructure Sites: Mounted on mobile cranes or work vehicles to monitor wind speed and weather for safety compliance.
Aviation Ground Support: Used in airport mobile units to collect on-site weather data for ground operations.
